Description
MSC15 Series
Medical Grade AC/DC Power Supply
MSC series has been specifically designed with the medical industry in mind. The new AC/DC Supply has been approved to the latest safety approval standard EN60601-1 and have the highest level of insulation, 2MOPP indicating they are suitable for each kind of Medical Application
Output Voltage Adjustment
It allows the user to increase or decrease the output voltage of the module. This is accomplished by connecting an external resistor between the Trim pin and either the +Vout or -Vout pins. With an external resistor between the Trim and -Output pin, the output voltage increases. With an external resistor between the Trim and +Output pin, the output voltage decreases. More information can be found on the datasheet.
Main Features
- Input voltage: 85-264VAC, 120-370VDC
- Output Voltage: 3.3V, 5V, 7.5V, 9V, 12V, 15V, 18V, 24V, 28V, 36V, 48V, & 53V
- 4000VAC Input to Output Isolation
- Built-in EN55032 EMI Class B Filter
- IEC60601-1 3RD edition safety approvals
- Wide operating temperature
- 5-year warranty
- Operating altitude 5000m
- Output voltage adjustable
- Chassis and DIN Rail Mounting
