Lead Acid Battery Monitoring System
PBAT-Gate Battery Monitoring System for UPS & Data Centres
Integrated by both web system and hardware devices, the PBAT-Gate Battery Monitoring System provides 24/7/365 real-time view of battery health and data analysis by reports. The real-time alarm allows you to make quick responses to battery issues and thus to avoid costly business loss. With voltage equalization/balancing feature, the uptime of battery backup can be maximised and costs of maintenance & replacement can be minimised. Read More about our Lead Acid Battery Monitoring System.
Features
- 24/7 Hours Online Monitoring & Remote Alarms Notification
- Suitable for UPS and Data Centre Application
- Report of battery string voltage & current, individual battery voltage, temperature and impedance
- Setpoint alarm for cell voltage, internal temperature, impedance, SOC, SOH (upper limit, lower limit)
- Setpoint alarm for cell string voltage, current, SOC (upper limit/lower limit)
- Anti-interference design allows connection with High-frequency UPS
- Build-in web server with visual display
- Local display via HMI
- Online balancing
- Online remote firmware upload
- Auto-sensing for the battery sensor’s ID Address
- Multi-communication protocol (MODBUS-TCP, SNMP)
- Support 4G sending SMS alarm
- Apply with IEEE 1188-2005 Standard
How does it work?
Cell Sensor:
- Measure cell voltage, internal impedance and cell temperature from negative pole.
- Each cell sensor communicates with each other through DL-BUS protocol. Data is uploaded to PBAT600 via RJ11 cable.
String Sensor:
- Measure string voltage, charge & discharge current via Hall sensor.
- Send order to cell sensor to calculate SOC & SOH.
- Equalize voltage of whole string.
Gateway:
- Store and analyse data it collects.
- With a built-in web server, all data can be displayed on web page system.
- Report for battery, such as string voltage & current, cell voltage, cell temperature, cell impedance.
- Pinpointing alarm for battery problems/issues.
- SMS alarm.
- Available for Modbus-TCP/IP and SNMP communication protocol.
- Measure ambient temperature & humidity
